CIQTEK participated in the TMS 2026 Annual Meeting & Exhibition, held from March 15–19, 2026 in San Diego, California, USA. Our U.S. team and local distribution partner welcomed visitors at Booth #307, where we presented our latest electron microscopy solutions for materials science applications.
About TMS 2026
Organized by The Minerals, Metals & Materials Society (TMS), this annual meeting is a key event for the global materials science community. It brings together researchers, engineers, and industry professionals working in areas such as metallurgy, advanced materials, additive manufacturing, and characterization technologies.
The event provides a strong platform for exchanging ideas, discovering new technologies, and discussing real-world challenges in materials research and production.
Tailored SEM Solutions for Materials Research
CIQTEK showcased electron microscopy solutions designed to support a wide range of materials science applications.
Our systems are well-suited for:
Microstructure analysis of metals and alloys
Failure analysis and defect investigation
Powder and particle characterization
Additive manufacturing and new materials research
Many visitors were particularly interested in how CIQTEK systems deliver stable imaging performance while remaining easy to operate. For labs balancing performance, usability, and budget, this combination is especially important.
We also had in-depth discussions with users about their daily challenges, such as improving imaging efficiency, simplifying workflows, and handling complex samples. These conversations help us better align our solutions with real application needs.
Strong Local Presence and Support in the U.S.
Participation in TMS 2026 is part of CIQTEK's broader strategy to expand its electron microscopy business in the U.S. market.
We offer:
A U.S.-based demo center for hands-on evaluation
U.S. Local technical and application support
Faster response for service and training
We continue to invest in local teams, infrastructure, and partnerships to support researchers and industry users better. By combining competitive technology with localized service, CIQTEK aims to make high-quality electron microscopy more accessible across North America.
Ultra High-Resolution Tungsten Filament Scanning Electron Microscope The CIQTEK SEM3300 Scanning Electron Microscope (SEM) incorporates technologies such as "Super-Tunnel" electron optics, inlens electron detectors, and electrostatic & electromagnetic compound objective lens. By applying these technologies to the tungsten filament microscope, the long-standing resolution limit of such SEM is surpassed, enabling the tungsten filament SEM to perform low-voltage analysis tasks previously only achievable with field emission SEMs.
Ga+ Focused Ion Beam Field Emission Scanning Electron Microscope The CIQTEK DB550 Focused Ion Beam Scanning Electron Microscope (FIB-SEM) has a focused ion beam column for nano-analysis and specimen preparation. It utilizes “super tunnel” electron optics technology, low aberration, and non-magnetic objective design, and has the “low voltage, high resolution” feature to ensure its nanoscale analytical capabilities. The ion columns facilitate a Ga+ liquid metal ion source with highly stable and high-quality ion beams to ensure nanofabrication capabilities. The DB550 is an all-in-one nano-analysis and fabrication workstation with an integrated nano-manipulator, gas injection system, and user-friendly GUI software.
Ultra-High Resolution Field Emission Scanning Electron Microscopy (FESEM) The CIQTEK SEM5000X is an ultra-high resolution FESEM with optimized electron optics column design, reducing overall aberrations by 30%, achieving ultra-high resolution of 0.6 nm@15 kV and 1.0 nm@1 kV. Its high resolution and stability make it advantageous in advanced nano-structural materials research, as well as the development and manufacturing of high-technology node semiconductor IC chips. Contact our U.S. team: info.usa@ciqtek.com
