Recently, the world's first commercial low-temperature Scanning Nitrogen-vacancy Probe Microscope (SNVM) was released in Hefei, Anhui, China. This instrument is mainly used to detect the surface magnetism of nanomaterials and will provide a new method for research in fields such as materials science, condensed matter physics, and life sciences. The instrument was independently developed by CIQTEK, marking a new breakthrough in the industrialization development of precision measurement technology. Precision measurement refers to the use of properties such as energy level transitions, coherent superposition, and entanglement to achieve substantial improvements in measurement accuracy, sensitivity, resolution, etc. The CIQTEK Scanning Nitrogen-vacancy Probe Microscope (SNVM) is an advanced scientific analytical instrument that combines diamond nitrogen-vacancy (NV) optical detected magnetic resonance (ODMR) technology and atomic force microscope (AFM) scanning imaging technology, which can realize quantitative and non-destructive magnetic imaging of magnetic samples with high spatial resolution and high sensitivity. In addition to diamond NV color centers, there are many technical routes for precision measurement, including atomic magnetometers, atomic clocks, etc. Atomic magnetometer is a technology that uses the interaction between light and atoms to detect magnetic fields, which can detect coronary heart disease and abnormal heart rate. As a new generation of atomic clock, optical lattice clock can currently achieve an error of only 1 second in tens of billions of years. Each technical route shows its unique capabilities according to the application scenarios. SNVM for Magnetic Imaging of BFO Films Precision sensors are known as "a key to the microscopic world." It is not only small, but also very sensitive. It can detect many signals that were undetectable and inaccurate in the past, such as brain magnetism and cardiac magnetism. It can be used for early diagnosis of neurological diseases, coronary heart disease and other diseases. At the same time, precision measurement has also brought about some innovations in detection methods, such as leakage current detection in lithium batteries in the new energy field, power grid management in the energy exploration field, and chip current imaging in the semiconductor/integrated circuit field. SNVM for Imaging A Single Vortex Stray Magnetic Field The industry regards precision measurement as another "ripe industrialization" direction in the field of information technology, and technological innovation is becoming increasingly active. In recent years, many start-up companies in the field of measurement have been hatched around the world to explore various application scenarios and promote the progress of commercialization. SNVM for Twisted Bilayer CrI3 Measurements Precision measurement is to change "invisible" to "visible"...
View MoreThe demo lab at Loughborough University is buzzing with excitement as we showcase the cutting-edge Scanning Electron Microscope SEM3200, a revolutionary addition to the UK market. In collaboration with the renowned Loughborough Materials Characterization Center (LMCC), SciMed is proud to introduce users to the new range of CIQTEK microscopes, backed by the world-leading expertise of the facility staff. Loughborough University is no stranger to excellence. Ranked among the top 10 universities in the UK, it boasts a rich academic legacy and a commitment to scientific progress. Housed within the LMCC, an acclaimed state-of-the-art material analysis facility, the demo lab provides the perfect environment to unveil the SEM3200 and its exceptional capabilities. Our journey began by collating images from various research groups closely affiliated with Loughborough University. We worked closely with these groups, enabling me to gather diverse samples for imaging. From micropatterned substrates produced through photolithography to the intricate surface of a microelectrode array, they have captured the essence of materials under the microscope. Furthermore, they have recently obtained a range of materials used in hydrogen energy cell technologies, expanding the possibilities of our imaging capabilities. The feedback from the staff has been overwhelmingly positive. Universally, they have praised the user-friendly software interface, which allows for intuitive control within minutes of use. One standout feature is the eucentric 5-axis stage, which ensures impeccable focus and image position, even during significant changes in tilt angle. The SEM3200's modern design has truly impressed our users, as it effortlessly produces high-quality images with remarkable ease. The SEM3200 represents a leap forward in microscopy technology, and its arrival at Loughborough University's demo lab is a cause for celebration. Researchers, scientists, and students alike can now access a microscope that combines world-class expertise with user-friendly operation, paving the way for groundbreaking discoveries and exceptional research outputs. Step into the future of microscopy with the SEM3200. Experience the power of cutting-edge technology, supported by the top-tier infrastructure of Loughborough University's LMCC. Join us at the demo lab and witness firsthand the incredible potential of the SEM3200. Together, let's explore new frontiers and unlock a world of microscopic wonders.
View MoreFIB-SEM can be used for defect diagnosis, repair, ion implantation, in-situ processing, mask repair, etching, integrated circuit design modification, chip device production, and mask-less processing of large-scale integrated circuits. Nanostructure production, complex nanopattern processing, three-dimensional imaging and analysis of materials, ultra-sensitive surface analysis, surface modification, and transmission electron microscopy sample preparation, etc. It has a wide range of application requirements and is indispensable. CIQTEK DB500 is a Field Emission Scanning Electron Microscope (FE-SEM) with a Focused Ion Beam (FIB) column for nano analysis and specimen preparation, which is applied with “SuperTunnel” electron optics technology, low aberration, and magnetic-free objective lens design, with low-voltage and high-resolution ability that ensures its nano-scale analytical capability. The ion column facilitates a Ga+ liquid metal ion source with a highly stable and high-quality ion beam to ensure nano-fabrication capability. DB500 has an integrated nano-manipulator, gas injection system, electrical anti-contamination mechanism for the objective lens, and 24 expansion ports, making it an all-around nano-analysis and fabrication platform with comprehensive configurations and expandability. In order to demonstrate the outstanding performance of DB500 to users, the Electron Microscopy team has specially planned the special program " CIQTEK FIB Show", which will present the wide range of applications in the fields of materials science, semiconductor industry, biomedicine, etc. in the form of video. The audience will understand the working principle of DB500, appreciate the stunning microscopic images it captures, and deeply explore the significance of this technology to scientific research and industrial development. TEM sample preparation In this episode, we will show you how DB500 can prepare transmission electron microscope (TEM) samples efficiently and accurately. As you can see from the video, DB500 prepares TEM samples with simple operation, few pre-processing steps, low learning costs, and efficient testing; it can achieve precise micro- and nanoscale cutting at fixed points, with controllable size and uniform thickness, and is suitable for a variety of microscopy and Microscopic spectroscopy analysis; and the integration of cutting, imaging, and analysis can be achieved.
View MoreContinuing with the previous research and article, Cornell University researcher - Jess Whittemore, used a demonstration to show the process of capturing and quantifying free radicals emitted from cigarettes to investigate the harmful effects of free radicals which in addition to tars may lead to cancer. To analyze the spectra of free radicals in samples, she used the benchtop ESR spectrometer developed by CIQTEK. As she described "The CIQTEK benchtop spectrometer is rather compact which is a great advantage for using in all kinds of laboratory. But beyond that it has remarkable sensitivity for our ESR studies. For this reasons we believe that this benchtop ESR spectrometer by CIQTEK is the best on the market. "
View MoreRecently, CIQTEK Benchtop Electron Paramagnetic Resonance Spectrometer EPR200M was successfully delivered to Prof. Lee Eunsung's group at Seoul National University, marking that CIQTEK's EPR detection technology and product performance have been recognized by Korean users. CIQTEK EPR Helps Research on Novel Catalytic Materials Founded in 1946, Seoul National University is one of the earliest national comprehensive universities in Korea, and its teaching and research levels are among the highest in the world. The main research interests of the professor's group that introduced the CIQTEK EPR200M are new materials and catalysis, with a focus on fundamental organometallics and main group chemistry. The EPR200M will be specifically applied to the detection of newly synthesized novel stabilized stable organic radicals, which will aid in the development of organic MRI contrast agents and quantum bit materials. Recently, our agent has completed the preliminary user training, during the training process, the user said: CIQTEK EPR200M product stability, sensitivity indicators and data accuracy fully meet the requirements of the group's experimental testing. EPR through the measurement of a variety of free radicals in a variety of signal parameter changes in the material samples can be dynamically and quantitatively monitor the concentration of the increase or decrease, thus helping the research and development of new metathesis catalysts for cyclic and degradable polymers. Benchtop Electron Paramagnetic Resonance Spectrometer EPR200M The EPR200M is a newly designed, ergonomic benchtop electron paramagnetic resonance spectrometer. Based on high sensitivity, high stability, and a variety of experimental scenarios, it provides every EPR user with a cost-effective, low-maintenance, simple and easy-to-use experience. Products + Services: Committed to Creating a Leading Brand in EPR Technology Electron paramagnetic resonance (EPR) technology is a significant magnetic resonance analysis technique with important and extensive applications in chemistry, environmental science, materials physics, biomedical sciences, food, and industrial fields. CIQTEK has currently launched a full range of X-band EPR spectrometers with core proprietary intellectual property rights for commercial use: the X-band Pulse EPR Spectrometer EPR100, the X-band Continuous Wave EPR Spectrometer EPR200-plus, and the Benchtop EPR Spectrometer EPR200M. Additionally, we have broken through advanced high-end technology to develop the high-frequency W-band Pulse EPR Spectrometer EPR-W900. Based on its extensive experience in the field of EPR technology, CIQTEK has built a team of experts with rich application experience and multidisciplinary backgrounds. This enables CIQTEK to not only offer users a diverse selection of products but also assist users in solving application and interpretation challenges during use.
View MoreIn January 2024, CIQTEK's benchtop electron paramagnetic resonance spectrometer EPR200M was successfully delivered to Cornell University for research and teaching in the biomedical field. Cornell University researchers have carried out a number of biomedical research and teaching work based on the EPR200M. The product's simple operation experience, accurate test results, and the prompt service of CIQTEK engineers were well received by the users. They sent a letter of thanks after the delivery of the product: "We find the spectrometer very sensitive and convenient in operation". Jess Whittemore from Cornell University used a video to show the process of testing solid, liquid samples using the EPR200M.
View MoreWe are excited to announce that the new distribution agreement was signed with AXT which will distribute our Diamond Microscope (DM) and Educational Diamond Computer. The following is reprinted from AXT. CIQTEK is the developer and manufacturer of world-leading precision measurement technologies. Established in 2016 they have rapidly grown and currently have over 700 employees of which 70% are in their R&D team and have over 800 customers around the world. They originated from the Key Laboratory of Microscale Magnetic Resonance of the Chinese Academy of Sciences, University of Science and Technology of China and are responsible for over 200 patents, software copyrights and intellectual property assets (pending and granted). CIQTEK’s Diamond Microscope (DM) is a wide-field magnetic resonance instrument based on the principle of spin magnetic resonance in the diamond nitrogen-vacancy centre (NV centre). It offers ultra-high spatial resolution (up to 400nm), high sensitivity (5μT√HZ per pixel) fast imaging and a large field of view (1mm x 1mm). Ideally suited to the characterisation of semiconductors, it also has applications in geology and cell biology. Their Educational Diamond Computer is a teaching instrument based on the diamond’s spin magnetic resonance of the nitrogen-vacancy centre. The desktop design makes it easy to adapt to classrooms, laboratories, and other settings for conducting mechanics and computing experimental courses, while the ability to ability to operate at room temperature (i.e. no cryogenic cooling is necessary) almost negates operating costs. Richard Trett, AXT’s Managing Director commented, “Semiconductors are prioritised national growth areas in Australia. CIQTEK’s products are essential to these areas of research and we hope to remain ahead of the demand for our community, offering them cutting-edge tools so they can continue to push the boundaries of science.” CIQTEK’s Senior Engineer, Dr. Eric Xu replied, “We see the growth potential in Australia and we share AXT’s vision and look forward to working with them to satisfy the needs of Australian researchers”. AXT currently represents over 50 suppliers from around the world. Their portfolio caters for materials science, life science, mining and mineral and non-destructive testing.
View MoreResults Brief Appl. Catal. B:Porous graphitized carbon-supported FeOCl as a bifunctional adsorbent-catalyst for the wet peroxide oxidation of chlorinated volatile organic compounds: Effect of mesopores and mechanistic study Wet scrubbing combined with adsorption-enhanced heterogeneous advanced oxidation processes (AOPs) is an effective method to treat chlorinated volatile organic compounds (CVOCs). A porous graphitized carbon (PGC)-loaded FeOCl catalyst was developed by the group of Mr. Jinjun Li from Wuhan University for the effective removal of gaseous dichloroethane, trichloroethylene, dichloromethane, and chlorobenzene. The PGC-loaded FeOCl catalyst was characterized by BET and analyzed for adsorption performance, and it was found that the PGC-loaded FeOCl catalyst had a well-developed mesoporous structure, which could accelerate the diffusion of organic molecules within the particles, and showed better removal performance for CVOCs. CIQTEK EASY-V series products used in the study Chem. Eng. J:Micro-mesoporous graphitized carbon fiber as hydrophobic adsorbent that removes volatile organic compounds from air Activated carbon fibers (ACFs) are a popular class of adsorbents for volatile organic compounds (VOCs). Mr. Jinjun Li's group at Wuhan University prepared hydrophobicity-enhanced porous graphitized carbon fibers (PGCFs) by KOH-catalyzed graphitization and studied their adsorption capacity of representative VOCs, which was characterized to show that PGCFs have a high specific surface area of more than 2,200 m2/g and a micromediaturized pore structure, and that selective adsorption capacity of organics was improved under humid conditions. CIQTEK EASY-V series products used in the study Chem. Eng. J:Bamboo-derived hydrophobic porous graphitized carbon for adsorption of volatile organic compounds Hydrophobic bamboo-based porous graphitized carbons (BPGCs) were prepared by a composite catalytic graphitization method to study their adsorption performance on toluene, cyclohexane and ethanol, and the specific surface area sizes and micromesopore ratios of the carbon materials prepared at different synthesis temperatures were tested by BET characterization, which provides some theoretical support for evaluating the adsorption performance of carbon materials. CIQTEK EASY-V series products used in the study Material Adsorption Property Testing Technology Photocatalytic-driven CO2 reduction coupled with photo-oxidative conversion of plastic wastes into value-added chemicals is an effective strategy to address the greenhouse and environmental crises. The porous graphitized carbons (PGCs) and PGC-loaded FeOCl catalysts (FeOCl/PGCs) synthesized at different ratios were characterized by a specific surface and pore size analyzer, and the N2 adsorption and desorption isotherms are shown below in Fig.1d. The adsorption of N2 by PGC0 and FeOCl/PGC0 was mainly in the low relative pressure band at P/P0< 0.1, which is a typical micropo...
