The 2nd IESMAT Electron Microscopy Day was successfully held on November 6, 2025, in Madrid, Spain, bringing together dozens of microscopy experts, researchers, and professionals from Spain and Portugal. The event served as a valuable platform for sharing knowledge, exploring the latest microscopy technologies, and strengthening connections within the Iberian microscopy community. As CIQTEK’s official partner in Spain and Portugal, IESMAT provides localized support and professional service for CIQTEK electron microscopy solutions in the region. This year, the event was also recognized by the Portuguese Society of Microscopy, further expanding its reach and influence among the scientific and industrial communities. During the meeting, IESMAT presented an in-depth introduction to CIQTEK’s electron microscope product portfolio, highlighting advanced features and application advantages of the CIQTEK SEM series. A live demonstration using the CIQTEK Tungsten Filament SEM3200 allowed attendees to experience its high-resolution imaging capabilities and intuitive operation firsthand. The hands-on session sparked active discussions, with many participants engaging directly with IESMAT experts for technical insights and practical guidance. IESMAT Demonstrating the CIQTEK SEM3200 The event also featured a series of technical presentations and open discussions on microscopy applications across materials science, nanotechnology, and life sciences, reflecting the growing interest and demand for high-performance, user-friendly microscopy tools in the Iberian market. Looking ahead, CIQTEK and IESMAT will continue to deepen their collaboration to provide cutting-edge electron microscopy technologies, comprehensive customer support, and training opportunities to researchers and laboratories in Spain and Portugal. Together, they aim to empower scientific discovery and innovation through accessible, high-quality instrumentation.
View MoreResearchers from Nanjing University of Science and Technology, led by Prof. Erjun Kan and Assoc. Prof. Yi Wan, together with Prof. Kaiyou Wang’s team at the Institute of Semiconductors, Chinese Academy of Sciences, has achieved a breakthrough in the study of two-dimensional (2D) ferromagnetic semiconductors. Using the CIQTEK Scanning NV Microscope (SNVM), the team successfully demonstrated room-temperature ferromagnetism in the semiconducting material MnS₂. The findings were published in the Journal of the American Chemical Society (JACS) under the title “Experimental Evidence of Room-Temperature Ferromagnetism in Semiconducting MnS₂.” https://pubs.acs.org/doi/10.1021/jacs.5c10107 Pioneering Discovery in 2D Ferromagnetic Semiconductors The discovery of 2D ferromagnetic semiconductors has raised great expectations for advancing Moore’s Law and spintronics in memory and computation. However, most explored 2D ferromagnetic semiconductors exhibit Curie temperatures far below room temperature. Despite theoretical predictions of many potential room-temperature 2D ferromagnetic materials, the experimental synthesis of ordered and stable metastable structures remains a formidable challenge. In this study, the researchers developed a template-assisted chemical vapor deposition (CVD) method to synthesize layered MnS₂ microstructures within a ReS₂ template. High-resolution atomic characterizations revealed that the monolayer MnS₂ microstructure crystallized well in a distorted T-phase. The optical bandgap and temperature-dependent carrier mobility confirmed its semiconducting nature. By combining vibrating sample magnetometry (VSM), electrical transport measurements, and micro-magnetic imaging using CIQTEK SNVM, the team provided solid experimental evidence of room-temperature ferromagnetism in MnS₂. Electrical transport measurements also revealed an anomalous Hall resistance component in the monolayer samples. Theoretical calculations further indicated that this ferromagnetism originates from short-range Mn–Mn interactions. This work not only confirms the intrinsic room-temperature ferromagnetism of layered MnS₂ but also proposes an innovative approach for the growth of metastable functional 2D materials. Two Key Breakthroughs Intrinsic Room-Temperature Ferromagnetism in MnS₂ Monolayers:The study experimentally demonstrates intrinsic room-temperature ferromagnetism in semiconducting MnS₂, resolving the long-standing conflict between semiconductivity and magnetism. Template-Assisted CVD Strategy for Metastable Ferromagnetic Microstructures:The developed synthesis strategy enables scalable fabrication of metastable ferromagnetic microstructures. These advances establish MnS₂ as a model platform for 2D spintronics, offering a new pathway for engineering low-dimensional magnetic materials. ChatGPT 说: Figure 1: Optical and Magnetic Measurements Figure 2: Micro-Region Magnetic...
View MoreThe 15th China Symposium on Electron Paramagnetic Resonance (EPR) Spectroscopy was successfully held at Chongqing University from October 24 to 27, 2025. Nearly one hundred experts, scholars, industry representatives, and graduate students gathered to discuss cutting-edge topics in the EPR field, including new techniques and theories, biological spin labeling, and new energy applications. Grand Launch: CIQTEK Q-Band EPR Spectrometers Make a Stunning Debut As a pioneer in paramagnetic resonance technology, CIQTEK officially unveiled its new Q-band EPR spectrometer series — the EPR-Q400 High-Frequency Pulse Spectrometer and the EPR-Q300 Continuous-Wave Spectrometer, marking another significant milestone in high-frequency EPR technology. Compared with traditional X-band EPR, high-frequency EPR offers: Higher spectral resolution Stronger orientation selectivity Enhanced sensitivity Making it a powerful tool for biomacromolecular structure studies, spin dynamics research, and materials science applications. Dr. Richard Shi from CIQTEK Introduces the New Q-Band EPR Instruments at the Meeting Flagship Model: EPR-Q400 High-Frequency Pulse Spectrometer The EPR-Q400, the flagship model of this release, supports both CW and pulsed EPR measurements, meeting a wide range of research demands. It enables variable-temperature experiments from 4 K to 300 K, providing flexible and precise experimental conditions. Notably, the Q-band spectrometer adopts the same software platform as CIQTEK X-band EPR systems, greatly reducing the learning curve and ensuring a seamless and user-friendly operation experience. Dedicated CW Solution: EPR-Q300 Continuous-Wave Spectrometer For users focusing solely on continuous-wave EPR experiments, CIQTEK introduced the EPR-Q300, offering a targeted and efficient solution for diverse scientific applications. Continuous Innovation in EPR Technology This product launch showcases CIQTEK’s robust R&D capabilities and in-depth technical expertise in EPR spectroscopy, thereby further enriching its EPR product portfolio. During the symposium, multiple experts recognized CIQTEK’s responsive and professional technical support, noting that the team not only helps resolve experimental challenges but also actively participates in collaborative research, contributing to high-level scientific achievements. Upcoming Event: CIQTEK Paramagnetic Academy 2026 To further promote academic exchange and talent development in EPR technology, the CIQTEK Paramagnetic Academy Advanced EPR Workshop will be held from July 17 to 27, 2026, in conjunction with the CIQTEK EPR User Symposium. These events will serve as an open platform for technical communication, experience sharing, and application discussions among EPR researchers and users.Stay tuned for more updates and upcoming event announcements.
View MoreA research team led by Prof. Haomin Wang from the Shanghai Institute of Microsystem and Information Technology, Chinese Academy of Sciences, has achieved significant progress in studying the magnetism of zigzag graphene nanoribbons (zGNRs) using the CIQTEK Scanning NV Microscope (SNVM). Building on their previous research, the team fabricated oriented atomic grooves in hexagonal boron nitride (hBN) by pre-etching with metal nanoparticles and synthesized chiral-controlled graphene nanoribbons within these grooves through a vapor-phase catalytic CVD method. The resulting ~9 nm-wide zGNRs embedded in the hBN lattice exhibited intrinsic magnetic properties, which were directly confirmed experimentally for the first time using SNVM combined with magnetic transport measurements. This groundbreaking work lays a solid foundation for developing graphene-based spintronic devices. The study, titled “Signatures of magnetism in zigzag graphene nanoribbons embedded in a hexagonal boron nitride lattice”, was published in the renowned journal Nature Materials. https://doi.org/10.1038/s41563-025-02317-4 Understanding Graphene Magnetism Graphene, as a unique two-dimensional material, exhibits p-orbital electron magnetism that differs fundamentally from the localized d/f orbital magnetism found in conventional materials. This distinction opens new directions for exploring carbon-based quantum magnetism. Zigzag graphene nanoribbons (zGNRs) are particularly promising for spintronic applications because of their predicted magnetic electronic states near the Fermi level. However, detecting zGNR magnetism through electrical transport measurements has remained highly challenging. The main difficulties include the limited length of bottom-up synthesized nanoribbons, which complicates device fabrication, and the chemically reactive edges that lead to instability or inhomogeneous doping. Furthermore, in narrow zGNRs, strong antiferromagnetic coupling between edge states makes it difficult to electrically detect magnetic signals. These challenges have hindered direct observation of intrinsic magnetism in zGNRs. SNVM Reveals Magnetic Signals at Room Temperature Embedding zGNRs within an hBN lattice enhances edge stability and introduces built-in electric fields, providing an ideal environment for studying magnetism. Using CIQTEK’s room-temperature SNVM, the researchers directly visualized magnetic signals in zGNRs for the first time under ambient conditions. Figure 1. Magnetic measurement of zGNRs embedded in a hexagonal boron nitride lattice using the Scanning NV Microscope In electrical transport measurements, the ~9 nm-wide zGNR transistors demonstrated high conductivity and ballistic transport behavior. Under magnetic fields, the devices showed pronounced anisotropic magnetoresistance, with resistance changes up to 175 Ω and a magnetoresistance ratio of approximately 1.3% at 4 K, which persisted up to 350 K. Magnetic hys...
View MoreCutting-edge research platform for micro/nanoscale material behavior studies The Center for Micro/Nanoscale Behavior of Materials at Xi’an Jiaotong University (XJTU) has established a comprehensive in-situ materials performance research platform based on the CIQTEK SEM4000 Field Emission Scanning Electron Microscope (FE-SEM). By integrating multiple in-situ testing systems, the center has achieved remarkable progress in the application of in-situ SEM techniques and advanced materials science research. Leading national research infrastructure The XJTU Center for Micro/Nanoscale Behavior of Materials focuses on the structure–property relationship of materials at the micro/nanoscale. Since its establishment, the center has published over 410 high-impact papers, including in Nature and Science, demonstrating outstanding scientific output. The center houses one of the most advanced in-situ materials performance research platforms in China, equipped with large-scale systems such as a Hitachi 300 kV environmental TEM with quantitative nanomechanical–thermal coupling capabilities and an environmental aberration-corrected TEM for atomic-scale in-situ studies of thermo-mechanical-gas interactions. Together, these instruments provide powerful technical support for frontier materials research. Efficient and seamless experience with CIQTEK SEM In 2024, the center introduced the CIQTEK SEM4000 Field Emission Scanning Electron Microscope.Dr. Fan Chuanwei, equipment manager at the center, remarked: “The resolution and stability of the CIQTEK SEM4000 perfectly meet our research demands. What impressed us most was the efficiency. It took less than four months from equipment installation to our first paper published using the system, and the entire process from procurement to operation and after-sales was highly efficient.” Regarding customized services, Dr. Fan added: “For our in-situ SEM experiments, CIQTEK tailored a real-time video recording module and designed customized adapter stages for various in-situ setups. The rapid response and flexibility of the CIQTEK team fully demonstrate their professional expertise.” Integrated in-situ testing capabilities The SEM4000 platform at XJTU has successfully integrated three core in-situ testing systems, forming a complete in-situ mechanical performance research capability. Bruker Hysitron PI 89 Nanomechanical Test System – Enables nanoindentation, tensile, fracture, fatigue, and mechanical property mapping. It has been extensively used in micro/nanoscale mechanical testing of semiconductor devices, leading to significant results in semiconductor materials research. KW In-situ Tensile Stage – Offers a loading range from 1 N to 5 kN and supports various grips, including standard compression/tension, compact tension, three-point bending, and fiber tensile testing. Combined with SEM imaging, it allows real-time correlation of mechanical data ...
View MoreCIQTEK continues to expand its presence in Europe with the establishment of an SEM demo station in Spain, operated by the trusted local distributor IESMAT. Located in Madrid, the demo station features a CIQTEK High-Performance and Universal Tungsten Filament SEM Microscope SEM3200, providing Spanish users with convenient access to live demonstrations, sample testing, and hands-on operation. The facility also offers professional Spanish-language service and technical consultation, helping local customers better understand and apply CIQTEK’s advanced electron microscopy technologies. Since the installation of the CIQTEK SEM3200, IESMAT has actively organized a series of seminars and workshops throughout 2025, typically held every one to two months. These events welcome researchers and professionals from academia and industry to explore the performance and advantages of CIQTEK scanning electron microscopes through hands-on sessions and interactive learning experiences. IESMAT SEM Workshop in January 2025 IESMAT SEM Seminar in Feb, 2025 IESMAT Most Recent SEM Seminar in Sep, 2025 The next event, IESMAT Electron Microscopy Day II, will take place on November 6, 2025, in Madrid. Participants will enjoy: Live hands-on electron microscopy with the CIQTEK SEM3200 Cutting-edge analytics using EDS and EBSD Insights into current trends and future directions of electron microscopy in Spain The SEM demo station at IESMAT marks an important milestone in CIQTEK’s European development strategy. It enhances local accessibility to advanced electron microscopy technologies and provides researchers with authentic, real-world experience. Through close collaboration with partners like IESMAT, CIQTEK is deepening its engagement with the European market, promoting innovation, and building stronger connections with the scientific community. CIQTEK remains committed to empowering global users through advanced instrumentation, localized service, and continuous collaboration for scientific progress.
View MoreThis week, CIQTEK was pleased to welcome the team from our Korean distributor GSEM to the CIQTEK Electron Microscope Factory in Wuxi, China. The visit included members from sales, application, and service departments, who participated in a series of intensive and professional training sessions focused on electron microscope operation and maintenance. The CIQTEK Electron Microscope Factory serves as the company’s dedicated manufacturing and training center for electron microscopy systems. Equipped with advanced production facilities, precision assembly lines, and demonstration laboratories, the factory integrates R&D, manufacturing, quality control, and user training to ensure high performance and reliability across CIQTEK SEM, FIB-SEM, and TEM product lines. The training was hosted by Mr. Gao, Head of the Electron Microscopy Solutions Department at CIQTEK, together with senior engineers from the CIQTEK electron microscopy team. During the program, participants received systematic instruction on key procedures such as ion pump baking, aperture position inspection, filament centering, high-resolution imaging practice, and accessory installation and calibration. Throughout the week, the GSEM team worked closely with CIQTEK engineers to gain both theoretical and practical understanding of CIQTEK’s electron microscopy technology. The sessions were designed to ensure that GSEM’s sales and service engineers are fully equipped with the technical expertise required to support local customers in Korea, from system installation and operation to advanced troubleshooting and maintenance. This training not only enhanced GSEM’s technical capabilities but also strengthened the partnership between CIQTEK and GSEM. With continuous collaboration in product knowledge, application support, and customer service, CIQTEK and GSEM will jointly provide more professional, efficient, and reliable solutions to the Korean electron microscopy market. CIQTEK remains committed to empowering global partners through professional training, technical collaboration, and continuous innovation in scientific instrumentation.
View MoreCIQTEK successfully wrapped up its participation at BIOEXPO 2025, held from October 15–17 at the Istanbul Expo Center, Turkey. During the three-day event, the CIQTEK team welcomed researchers, partners, and industry professionals to Booth #414, where engaging discussions revolved around cutting-edge topics such as electron microscopy, magnetic resonance, and materials analysis. Visitors explored CIQTEK’s range of precision analytical instruments, including Electron Microscopes (FIB/SEM), NMR & EPR Spectrometers, and BET Surface Analyzers, and learned how these technologies empower innovation across life sciences, materials, and industrial research fields. The exhibition provided an excellent opportunity to connect with scientists, share expertise, and exchange ideas on the future of advanced measurement technologies in Turkey and beyond. “We were delighted to see the growing interest in CIQTEK’s high-performance solutions. Events like BIOEXPO allow us to better understand researchers’ needs and strengthen collaboration across borders,” said the CIQTEK team. CIQTEK extends sincere thanks to all visitors, partners, and organizers who made BIOEXPO 2025 a success. We look forward to meeting you again at the upcoming international exhibitions!
